GPU: The graphics card is built around the NVIDIA GeForce RTX 5070 GPU, featuring 6144 CUDA cores.
Memory: It is equipped with 12GB of GDDR7 video memory with a 192-bit interface, and a memory speed of 28 Gbps.
Clock speed: The OC (overclock) mode reaches a boost clock of 2685 MHz, while the default mode runs at 2655 MHz.
Cooling system: The card uses a triple Axial-tech fan design with a massive 3.2-slot heatsink for optimal airflow and efficient heat dissipation. Features also include a MaxContact design and phase-change GPU thermal pads for superior heat transfer.
Acoustics: The 0dB technology allows the fans to stop spinning during light gaming, enabling silent operation.
Power: Power is delivered through a single 16-pin connector. ASUS recommends a 750W power supply unit (PSU) for a fully overclocked system.
Build: The card has a protective backplate for structural rigidity and a protective PCB coating to guard against moisture and debris.
Connectivity: It offers extensive connectivity with two Native HDMI 2.1b ports and three Native DisplayPort 2.1b ports, with support for up to four displays.
Lighting: Integrated Aura Sync compatible ARGB lighting on the shroud and perimeter offers extensive customization.
Software: ASUS GPU Tweak III software provides advanced tuning and system monitoring.
AI and ray tracing: The card utilizes NVIDIA's Blackwell architecture and DLSS 4 to provide powerful AI performance and realistic, full ray-traced graphics. It also features NVIDIA Reflex 2 for reduced latency and NVIDIA Studio for accelerated creative applications.
Model
PRIME-RTX5070-12G
Graphic Engine
NVIDIA® GeForce RTX™ 5070
AI Performance
988 TOPs
Bus Standard
PCI Express 5.0
OpenGL
OpenGL®4.6
Video Memory
12GB GDDR7
Engine Clock
OC mode: 2542MHz
Default mode: 2512MHz (Boost Clock)
CUDA Core
6144
Memory Speed
28 Gbps
Memory Interface
192-bit
Resolution
Digital Max Resolution 7680 x 4320
Interface
Yes x 1 (Native HDMI 2.1b)
Yes x 3 (Native DisplayPort 2.1b)
HDCP Support Yes (2.3)
Maximum Display Support
4
NVlink/ Crossfire Support
No
Accessories
1 x Speedsetup Manual
1 x ASUS Velcro Hook & Loop
1 x Thank You Card
1 x Adapter Cable (1 to 2)
Software
ASUS GPU Tweak III & MuseTree & GeForce Game Ready Driver & Studio Driver: please download all software from the support site.
Dimensions
304 x 126 x 50 mm
12 x 5 x 2 inch
Recommended PSU
750W
Power Connectors
1 x 16-pin
Slot
2.5 Slot
SFF Ready
Compatible
