SPECIFICATIONS
Panel Size 24.5” (62.2cm)
Active Display Area (mm) 543.7 (H) x 302.6 (V)
Curvature Flat
Panel Type Rapid IPS
Panel Resolution 1920 x 1080 (FHD)
Pixel Pitch (H x V) 0.27156(H)x0.27156(V)
Aspect Ratio 16:9
Brightness (nits) 300
Contrast Ratio 1000:1
DCR 100000000:1
Signal Frequency 52.7KHz-198KHz / 48-180Hz(V)
ACTIVATED RANGE 48~180Hz
Refresh Rate 180Hz
Response time 1ms (GtG)
DYNAMIC REFRESH RATE
TECHNOLOGY AMD FreeSync™
HDR Support N/A
Video ports 1x Display Port (1.2a)
2x HDMI™ (2.0b)
USB ports N/A
Audio ports 1x Headphone out
Viewing Angle 178° (H) / 178° (V)
Adobe RGB / DCI-P3 / sRGB 82% / 78% / 99%
Surface Treatment Anti-glare
Display Colors 16.7M (8bits)
Frameless Design Yes
PIP / PBP Function N/A
Power Type Power Cable
Power Input 100~240V, 50/60Hz
Adjustment (Tilt)-5° ~ 20°
Adjustment (Swivel) N/A
Adjustment (Pivot) N/A
Adjustment (Height) N/A
Kensington Lock Yes
VESA Mounting 100 x 100mm
Weight (NW / GW) 3.24 / 5.13 (kg)
2.87kg(without stand)
Dimension (W x D x H)
Carton Dimension (W X D X H)
Note
CONNECTIONS
557.1 x 220.1 x 418.5 mm
557.1 x 66.4 x 326.9 mm (without
stand)
WW carton: 630 x 125 x 411 mm
Outer: 650 x 145 x 443 mm
Display Port: 1920 x 1080 (Up to 180Hz)
HDMI™: 1920 x 1080 (Up to 180Hz)
Adobe RGB, DCI-P3 and sRGB follow
CIE1976 Standard
