3 x DisplayPort 2.1b with UHBR20 (up to 4K 480Hz or 8K 165Hz with DSC) 1 x HDMI® Connector (Supports 4K 480Hz HDR or 8K 120Hz HDR with DSC, and Gaming VRR as specified in the HDMI 2.1b Specification)
HDCP Support
2.3
Multi Display Capability
Quad Display
Recommended Power Supply
600W
Power Consumption
180W
Power Input
1 x 8-pin power input
DirectX
Microsoft DirectX® 12 Ultimate
OpenGL
4.6
Cooling
IceStorm 2.0
Slot Size
2
SLI
No
Supported OS
Windows 11 / Windows 10 64-bit (v1809 November 2018 or later)
ROG-STRIX-RTX5070-O12G-GAMING
The ROG-STRIX-RTX5070-O12G-GAMING is an ASUS Republic of Gamers (ROG) Strix GeForce RTX 5070 OC Edition graphics card. It is powered by the NVIDIA Blackwell architecture and is designed for high-performance gaming.
Model
PRIME-RTX5070-12G
Graphic Engine
NVIDIA® GeForce RTX™ 5070
AI Performance
988 TOPs
Bus Standard
PCI Express 5.0
OpenGL
OpenGL®4.6
Video Memory
12GB GDDR7
Engine Clock
OC mode: 2542MHz
Default mode: 2512MHz (Boost Clock)
CUDA Core
6144
Memory Speed
28 Gbps
Memory Interface
192-bit
Resolution
Digital Max Resolution 7680 x 4320
Interface
Yes x 1 (Native HDMI 2.1b)
Yes x 3 (Native DisplayPort 2.1b)
HDCP Support Yes (2.3)
Maximum Display Support
4
NVlink/ Crossfire Support
No
Accessories
1 x Speedsetup Manual
1 x ASUS Velcro Hook & Loop
1 x Thank You Card
1 x Adapter Cable (1 to 2)
Software
ASUS GPU Tweak III & MuseTree & GeForce Game Ready Driver & Studio Driver: please download all software from the support site.
Dimensions
304 x 126 x 50 mm
12 x 5 x 2 inch
Recommended PSU
750W
Power Connectors
1 x 16-pin
Slot
2.5 Slot
SFF Ready
Compatible
